Graco T-Max

The T-max 506 and T-max 657  offer a real solution for the application of interior plasters and decorative texture materials. The machines run in either Airless or Air Assisted mode using the same lance by just changing the airless adaptor to the air assisted mode adaptor.  For air assisted mode applications a separate compressor is required. The unique design offers 1 person handling allowing the safe use, cleaning and loading / unloading of the unit by one person. The professional lance design offers a high quality of finish reducing smoothing to a minimum. The T-max can support a team of three people applying more than 500 square meters a day. A mixer mounting and a bag roller kit can be supplied as an optional extra and with the T-max being tested and approved to spray the most demanding plasters, mixed or premixed, that are currently on the market, in combination with an external compressor materials with a particle size upto 1.5mm can also be sprayed. Mount the fine finish kit at the end of the lance whilst spraying air assisted mode for easy control and even finish. This kit transforms the round spray pattern into a controlled fan. Cleaning could not be easier, flush the system with water. Clean hose by using flushing ball to scrape inside of hose clean. When clean remove the hopper and it’s drain bung for easy cleaning and clean around mating surfaces with warm water.

When combined with the light, ergonomic, quick and clean opening/closing lance which avoids spitting, with horizontal clog avoiding design the T-max system gives the professional finish in an efficient and comfortable manner.

The ready to spray T-Max 657 is supplied with

· Hopper, Lance, 10mtr material hose, 3mtr material whip end, 15mtr air hise

· 18 Mesh material filter

· Heavy duty airless spray set with Blue RAC X guard, RAC X Tip HDA661 30 Mesh Material Filter

· Fine finish air assisted spray set with 4mm nozzle , air nozzle guard and 4 different fan pattern discs

· Cleaning set flex scraper, filter scraper, cleaning ball, brush, air nozzle cleaner.

The ASM H3700  is the specialists choice for heavy duty use on both interior and exterior projects. Ideal for both residential, commercial and industrial sites. The unit is available in 110 volt or 240 volt. The most powerful electric unit in the ASM range it is capable of being supplied as a two gun setup. Ideally suited to Emulsions, Intumescents, Decorative , Acrylics, Blockfillers and light or ready mixed plasters.  With a maximum  working pressure of 230 bar (3300psi) , allowing a maximum tip size of 37 thou and a flow rate of up to 5.5 ltrs a minute this truly is the ideal heavy duty machine. Supplied ready to work with 15 mtrs of  3/8” hose, 1/4” whip end , Airless gun, tip guard and tip of choice.

Combine this unit with the 95Ltr capacity Plaster Hopper and bag roller and you have the perfect tool for the application of airless applied plasters.

ASM H3700 Airless Unit

· Supplied in either 110 or 240 volt

· Only 16 amp power supply required for 110 volt use

· Max tip size plaster 37 thou

· Max flow rate plaster 5.5 ltrs a minute

· Unit only weight 58 Kgs

· DC Brushless 1.65 KW motor

· Configurable two gun set up

· Robust frame  with back support

· Wheeled Hi Boy  for ease of transport

· Pneumatic Tyres

· 1 years manufacturers warranty

· 95 Ltr Capacity Plaster Hopper

· Plaster Hopper Bag Roller

· Plaster set Up  Return Hose

Hemo 10 Heavy Duty Airless

The HEMO 10 is an airless high pressure spray unit designed for spray applications of putty and heavy coating materials such as plaster. The HEMO 10 has been produced for more than 15 years and has an established and solid reputation as the leading electric high pressure unit for spray plaster and other heavy duty materials. Airless spraying gives considerable cleaner working environment with less noise and easy handling together with both technical and economical advantage:

· no need for compressor

· less dust and over spray

· precise application and texturing

· low noise level

· easy one hand maneuvered spray gun

· less consumption of plaster

· Minimum masking and covering



The HEMO 10 is used for application of spray plaster, spack, concrete filler, PVA-glue, asphalt emulsion and other kinds of heavy duty materials with a  grain size up to 0,6 mm that need high capacity. The fluid pump is a piston pump with three pistons and easy replaceable packings. The large fluid section and the powerful motor gives a capacity of approx. 12 Ltrs Per minute.

Motor	3 kW
Electr. requirement.	380V 3 phases 16A
Pump	hardened steel pistons
Length	1400 mm
Height	900 mm excl. bagemptier (1030 mm with bag emptier)
Width	650 mm
Weight	150 kg
Container	75 liter
Hose	1/2" standard, 5/8" option
Length of hose	10 m standard
Operating pressure	110-160 kg/cm²
Spray Gun	SPR25000
Spray Tips	max 0,095"
Capacity	12 l/minute (20 kg/minute)
Bag emptier	detachable reinforced glassfibre with wringer

Hemo 10 Technical Specification

· 3Kw Motor

· 380v 3 Phase 16amp requirement

· Hardened steel Pistons

· 75 Ltr Hopper With Fibreglass Bag Roller

· 10mtr 1/2” Hose

· Operating Pressure 110-160 kg cm2

· Maximum Tip Size 0.095” (thou)

· Total weight 150kgs

· Dimensions 1030mmH x 1400mmL x 650mmW

· Flow rate 12 Ltrs Per Minute

Motor	3 kW
Electr. requirement.	380V 3 phases 16A
Pump	hardened steel pistons
Length	1400 mm
Height	900 mm excl. bagemptier (1030 mm with bag emptier)
Width	650 mm
Weight	150 kg
Container	75 liter
Hose	1/2" standard, 5/8" option
Length of hose	10 m standard
Operating pressure	110-160 kg/cm²
Spray Gun	SPR25000
Spray Tips	max 0,095"
Capacity	12 l/minute (20 kg/minute)
Bag emptier	detachable reinforced glassfibre with wringer

SPR 6 Heavy Duty Screw Pump

The SPR6 6SM spray unit is designed for the application of premixed spray plaster and heavy coatings which contain aggregate to a maximum grain size of 2mm.

The SPR6 6SM is supplied with a frequency inverter, which allows the smooth control of the rotor allowing the stator speed to be set at the correct rate for the application, as opposed to the fixed belt method that is employed on other equipment.

As well as smooth plaster finishes texture finishes can be achieved easily using the variable speed control and air pressure regulation.

A compressor is required in conjunction with this machine and it must be capable of supplying air at 9cfm at 4-6 bar.

The unit is supplied complete with 10mtrs of material hose and gun and is usually supplied on 110volt.

SPR6 6SM Technical Specification

· 0.75—1.1 Kw Motor

· 110volt 16amp or 32amp single phase

· Flow rate 3—8 Ltrs minute

· 50 ltr Hopper with Fibreglass Bag Roller

· 10 Mtr 1” material Hose

· High flow gun

· Nozzles from 3 to 10mm

· Total weight 60 Kgs

· Dimensions 850mmH x 1200mmL x 560mmW
